Mori Seiki SL-15 CNC Lathe

Specifications:

Swing Over Bed 17.7"

Swing Over Cross Slide 11.8"

Between Centers 23.4"

Max. Machining Diameter 6.3"

Max. Machining Length 20.7"

X-Axis Travel 5.3"

Z-Axis Travel 22.0"

Spindle Speed 60 ~ 6000 rpm

Spindle Nose A2-5 Hole

Through Spindle 2.0"

Number of Turret Stations 12

Turret Index Time 0.7 sec

X-Axis Rapid Feed Rate 472.4 ipm

Z-Axis Rapid Feed Rate 590.6 ipm

Tailstock Stroke 17.7"

Quill Diameter 3.0"

Taper MT4

Quill Stroke 3.1"

Main Motor (30 min/cont) 7.5 / 5.5 HP

Required Floor Space 98.4" x 57.2"

Machine Weight 7,000 lbs.

Equipped With:

Fanuc 10T Control

Chip Conveyor

Misc Turret Tool Holders
