2012 HAAS TR-160 CNC 5 Axis Trunnion Rotary Table
2012 HAAS TR-160 CNC 5 Axis Trunnion Rotary Table
$15,000 (USD)
Hubbard, TX
orCall 817-714-9839
Description
2012 HAAS TR-160 CNC 5 Axis Trunnion Rotary Table
Spindle – A (Tilt)
Spindle – B (Rotary)
Indexing – A (Tilt)
Indexing – B (Rotary)
Specifications
| Manufacturer | Haas |
| Model | TR160 |
| Year | 2012 |
| Condition | Used |
| Platter diameter | 6.3 ” |
| Max weight on platter | 80 lbs. |
| Part swing max | 17.5 ” |
| Number of t-slots | 6@ 60° |
| Max speed | 0.001 to 80 °/sec |
| Max torque | 100 ft-lb |
| Backlash | 30 arc-sec |
| Gear ratio | 63:1 |
| Timing | 2:1 |
| Brake torque @ 100 psi/6.9 bar | 100 ft-lb |
| Runout max | 0.0005 ” |
| Pilot bore dia. (through) | 1.500 (+0.0005, -0) ” |
| Max rotation/step | 999.999 ° |
| Resolution | 0.001 ° |
| Accuracy (±) | 15 arc-sec |
| Repeatability | 10 arc-sec |
